• TPMH090304 CNC Carbide Inserts Fast Feed Carbide Lathe Inserts
  • TPMH090304 CNC Carbide Inserts Fast Feed Carbide Lathe Inserts
TPMH090304 CNC Carbide Inserts Fast Feed Carbide Lathe Inserts

TPMH090304 CNC Carbide Inserts Fast Feed Carbide Lathe Inserts

Product Details:

Place of Origin: China
Brand Name: BWIN
Model Number: TPMH090304

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs/box
Price: Negotiable
Packaging Details: Plastic box
Delivery Time: 7 work days
Payment Terms: T/T, Western Union
Supply Ability: 1-10000pcs 7days
Get Best Price Contact Now

Detail Information

Product Name: TPMH090304 Fast Feed Carbide Insert Material: Tungsten Cnc Lathe Tool
Workpiece: Steel/Stainless Steel Usage: Turning Cutting Insert
Color: Brown/Fuchsia Coating: PVD CVD
Hardness: HRC40-60 Feature: Corrosion Resistance
Application: Cnc Lathe Machine Package: 10pcs/Box
High Light:

Tpmh 090304 CNC Carbide Inserts

,

Carbide Lathe Inserts Tpmh 090304

,

Fast Feed Carbide Lathe Inserts

Product Description

TPMH090304 110304 Tungsten Carbide Lathe Inserts Tool Cnc Fast Feed Stainless Steel

Quick Detail:

  • High stiffness
  • High-precision
  • Thick layer
  • Corrosion resistance
  • Smooth chip breaking
  • High finish

Description:

  • TPMH CNC carbide inserts are made of high-quality cemented carbide materials, with fine workmanship, high strength, high toughness, and stronger wear resistance of the rear blade surface, making it stable and durable; Unique coating process, fine and smooth, no drip marks, reduce surface friction, so that the cutting resistance is smaller; The precision polishing treatment of the cutting groove of the blade effectively reduces the wear of the blade, improves the roughness of the processed product, and extends the service life of the blade; Sufficient supply, complete models, support non-standard customization.

Specifications:

Brand BWIN
Model TPMH090304 TPMH110304
Color Brown/Fuchsia
Workpiece Steel/Stainless steel
Type Turning Insert
Material Tungsten Carbide
Processing Type Medium Cutting
Feature High stiffness
High-precision
Thick layer
Corrosion resistance

Smooth chip breaking

Standard ISO
Quantity 10pcs/box
Weight 0.015kg
Package Plastic Box
Customized Support OEM, ODM



Lead Time:

antity(pieces) 1 - 3000 >3000
Lead time (days)  7 To be negotiated



Notice:

  • The cnc carbide inserts shall not be collided or dropped on the ground and must be handled with care.
  • Before installing the cnc carbide inserts, the performance and purpose of the saw table must be confirmed to ensure that the cutting direction indicated by the blade arrow is consistent with the rotation direction of the saw table. It is strictly prohibited to install in the opposite direction. Wrong installation direction may cause the blade sawtooth to fall off, so as to prevent accidents.
  • After installation, it is necessary to confirm whether the central hole of the cnc carbide insert are firmly fixed on the flange plate of the saw table. If there is a gasket, the gasket must be sleeved; Then, gently push with your hand to confirm whether the blade rotates eccentrically.
  • When using, do not exceed the specified high speed
  • When the cnc carbide inserts are not used, hang the blade vertically on the dry shelf.

Applications:

Our CNC carbide inserts could to be processed Alloy steel, Tool steel, carbon steel, stainless steel, Cast iron and Titanium alloy. Working material as following:

Cnc Tungsten Carbide Insert Cnmg 120404 120408 120412 Lathe Turning Cutting Tool

Advantage:

1. Distribution and wholesale, complete in variety

Large quantity is preferred, product specifications are complete, and the pattern is subdivided into processing technology levels to meet your processing needs for different angles and different workpieces;

2. Carefully selected materials with reliable quality

Every detail has been strictly checked, and better products have been meticulously created. They are cheap, stable, durable and have a long service life

3. Sufficient supply and large inventory

We have our own factory, with a large amount of inventory to provide you with sufficient supply, so you don't need to worry about the shortage crisis, so that you can use it with confidence. Support customization, large quantity and price can be discussed, welcome to consult.

4. After sales service

We have a complete after-sales system. Cooperation is not the end, it is the beginning. If you have after-sales problems, please contact us at any time, and we will solve them for you as soon as possible.



FAQ:
1. Flank Wear? Higher cutting resistance,Notch wear on flank, Poor roughness of surface, or deterioration of accuracy.
Soft grades, Excessive cutting speed, Small flank angle, Low feed.
Select a higher, wear-resistant grade, Reduce cutting speed, Increase flank angle, Increase feed.

2. Crater Wear? Uncontrolled chip,Poor surface quality,when finishing High speed processing carbon steel
Soft grades, Excessive cutting speed, Excessive feed, The strength of chip breaker Insufficiet.
Change to a higher wear-resistant grade, Reduce cutting speed, Reduce feed, Select a higher strength chip breaker.

3. Chipping? Sudden fracture of cutting edge(rake face and flank), Instability insert life
Toughness insufficient, Excessive feed rate, Strength of cutting edge insufficient, Instability of the tool.
Select a tougher grade, Decrease feed rate, Increase honing of cutting edge(chamfering to rounding), Increase the stability and setting angle

4. Insert Fracture? Cutting resistance increased Poor surface roughness.
Toughness insufficient, Excessive feed rate, Strength of cutting edge insufficient, Instability of the tool.
Select a tougher grade, Decrease feed rate, Increase honing of cutting edge(chamfering to rounding), Increase the stability and setting angle.

5. Plastic Deformation? Variation of dimension Nose wear, cutting edge drape or passivating.when processing alloy steel Poor surface roughness
Soft grade, Excessive cutting speed, Excessive cutting depth and feed rate, Overheat on cutting edge.
Select a higher red hardness cutting material, Decrease cutting speed, Decrease cutting depth and feed rate, Select a higher thermal conductivity cutting material(CVD+sufficient coolant).

6. Build-Up-Edge? Workpiece dissove with Cutting edge Poor surface roughness when finishing, Cutting resistance increased, Cutting soft materials.
Cutting speed too low, Cutting edge obtuse, Unsuitable tool material. Increase cutting speed,Increase rake angle, Select small sticking force.
