High Precision HRC55 Copper Coated Deep Groove Endmills 2 Flutes Deep Groove Flat End Mills
Product Details:
Place of Origin: | China |
Brand Name: | BWIN |
Model Number: | D1.5*20*d4*50L-4T |
Payment & Shipping Terms:
Minimum Order Quantity: | 1pcs/box |
---|---|
Price: | Negotiable |
Packaging Details: | Plastic box |
Delivery Time: | 7 work days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 1-10000pcs 7days |
Detail Information |
|||
Pproduct Name: | HRC55 Copper Coated Deep Groove Endmills | Model: | 2 Flutes Deep Groove Flat End Mills |
---|---|---|---|
Material: | Carbide Deep Groove Endmills | Workpiece: | Die Steel |
Usage: | CNC | Coating: | AlTiSiN |
HRC: | HRC55 | Feature: | High Precision |
Application: | CNC Milling Tool | Package: | 1pcs/Box |
Highlight: | HRC55 2 Flute End Mill,Copper Coated 2 Flute End Mill,Deep Groove Flat End Mills |
Product Description
Quick Details OF Deep Groove Milling Cutter
- nanocomposite coating
- Fully sharpened edge
- passivation treatment
- Large core diameter design
- Double Margin Design
- Fully ground spiral groove
Description OF Deep Groove End Mill
- HRC55 deep groove milling cutter adopts imported micro-particle tungsten steel base material, which has higher wear resistance and strength. It is more wear-resistant, reduces the number of tool changes, and also has super heat insulation; the stability of the increased length of the reasonable avoidance greatly reduces the chance of knife breakage; the universal chamfered round handle is easy to use, and the clamping is firmer and does not slip.
Milling Parameters OF Deep Groove Endmill
HRC55 Carbide Deep Groove End Mill | Tool length | fz&v | |||||
Short | 1 | ||||||
Long1 | 0.9 | ||||||
Overlength | 0.8 | ||||||
Speciality | 0.6 | ||||||
Type | Material | Strength N/mm² Hardness HRC |
Cooling | ||||
Air | Dry cutting | Lubricating fluid | |||||
P | PI | P1.1 | Non alloy structural steel, free cutting structural steel, carburized steel and quenched and tempered steel | <700 | √ | √ | √ |
P1.2 | quenched and tempered steel | <1200 | √ | √ | √ | ||
P2 | P2.1 | Alloyed nitrided steel, carburized steel and quenched and tempered steel | <900 | √ | √ | √ | |
P2.2 | Tool steel, bearing steel, spring steel and high-speed steel | <1400 | √ | √ | |||
P3 | P3.1 | Tool steel, bearing steel, spring steel and high-speed steel | <900 | √ | √ | √ | |
P3.2 | Tool steel, bearing steel, spring steel and high-speed steel | <1500 | √ | √ | |||
M | M1 | M1.1 | austenitic stainless steel | <700 | √ | √ | |
M1.2 | Ferritic/austenitic (bicrystal) stainless steel | <1000 | √ | ||||
M2 | M2.1 | Austenitic stainless cast steel | <700 | √ | √ | ||
M3 | M3.1 | Ferritic/austenitic (bicrystal) stainless cast steel | <1000 | √ | |||
K | K1 | K1.1 | Flake graphite cast iron (gray cast iron), GJL | <300 | √ | √ | √ |
K2 | K2.1 | Ductile iron, GJS | <500 | √ | √ | √ | |
K2.2 | Ductile iron, GJS | 500-800 | √ | √ | √ | ||
K2.3 | Ductile iron, GJS | >800 | √ | √ | √ | ||
K3 | K3.1 | Vermicular graphite cast iron, GJV; Malleable cast iron, GJM | <500 | √ | √ | √ | |
K3.2 | Vermicular graphite cast iron, GJV; Malleable cast iron, GJM | >500 | √ | √ | √ |
Slotting | ||||||||||
Vc (m/min) |
fz(mm/tooth) | |||||||||
Diameter | ||||||||||
2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | |
112 | 0.01 | 0.018 | 0.026 | 0.034 | 0.041 | 0.048 | 0.054 | 0.06 | 0.065 | 0.069 |
92 | 0.01 | 0.017 | 0.025 | 0.032 | 0.038 | 0.045 | 0.0505 | 0.056 | 0.061 | 0.065 |
100 | 0.01 | 0.018 | 0.026 | 0.034 | 0.041 | 0.048 | 0.054 | 0.06 | 0.065 | 0.069 |
72 | 0.009 | 0.015 | 0.022 | 0.028 | 0.034 | 0.04 | 0.045 | 0.05 | 0.054 | 0.058 |
64 | 0.01 | 0.018 | 0.025 | 0.032 | 0.039 | 0.045 | 0.051 | 0.057 | 0.062 | 0.066 |
56 | 0.009 | 0.016 | 0.023 | 0.029 | 0.036 | 0.041 | 0.0465 | 0.052 | 0.056 | 0.06 |
44 | 0.007 | 0.012 | 0.018 | 0.023 | 0.027 | 0.032 | 0.036 | 0.04 | 0.043 | 0.046 |
68 | 0.01 | 0.018 | 0.025 | 0.033 | 0.04 | 0.046 | 0.052 | 0.058 | 0.063 | 0.067 |
44 | 0.005 | 0.009 | 0.012 | 0.016 | 0.019 | 0.022 | 0.025 | 0.028 | 0.030 | 0.032 |
32 | 0.006 | 0.011 | 0.015 | 0.02 | 0.024 | 0.028 | 0.0315 | 0.035 | 0.0375 | 0.04 |
28 | 0.005 | 0.009 | 0.013 | 0.016 | 0.02 | 0.023 | 0.031 | 0.039 | 0.036 | 0.033 |
32 | 0.007 | 0.012 | 0.017 | 0.021 | 0.026 | 0.03 | 0.034 | 0.038 | 0.041 | 0.044 |
32 | 0.005 | 0.009 | 0.013 | 0.017 | 0.021 | 0.024 | 0.027 | 0.03 | 0.0325 | 0.035 |
120 | 0.017 | 0.031 | 0.044 | 0.056 | 0.068 | 0.08 | 0.09 | 0.1 | 0.05575 | 0.0115 |
112 | 0.015 | 0.026 | 0.037 | 0.048 | 0.058 | 0.068 | 0.0765 | 0.085 | 0.0915 | 0.098 |
92 | 0.012 | 0.022 | 0.031 | 0.039 | 0.048 | 0.056 | 0.063 | 0.07 | 0.0755 | 0.081 |
52 | 0.007 | 0.012 | 0.018 | 0.023 | 0.027 | 0.032 | 0.036 | 0.04 | 0.043 | 0.046 |
80 | 0.012 | 0.022 | 0.031 | 0.039 | 0.048 | 0.056 | 0.063 | 0.07 | 0.0755 | 0.081 |
76 | 0.01 | 0.018 | 0.026 | 0.034 | 0.041 | 0.048 | 0.054 | 0.06 | 0.0645 |
0.069 |
Roughing | ||||||||||
Vc (m/min) |
fz(mm/tooth) | |||||||||
Diameter | ||||||||||
2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | |
228 | 0.018 | 0.031 | 0.045 | 0.057 | 0.070 | 0.081 | 0.091 | 0.101 | 0.110 | 0.118 |
208 | 0.017 | 0.029 | 0.042 | 0.054 | 0.065 | 0.071 | 0.083 | 0.095 | 0.103 | 0.11 |
184 | 0.018 | 0.031 | 0.045 | 0.057 | 0.070 | 0.081 | 0.091 | 0.101 | 0.110 | 0.118 |
144 | 0.015 | 0.026 | 0.037 | 0.048 | 0.058 | 0.068 | 0.077 | 0.085 | 0.092 | 0.098 |
132 | 0.017 | 0.03 | 0.042 | 0.054 | 0.066 | 0.077 | 0.087 | 0.096 | 0.104 | 0.112 |
112 | 0.015 | 0.027 | 0.039 | 0.05 | 0.060 | 0.07 | 0.079 | 0.088 | 0.095 | 0.102 |
92 | 0.012 | 0.021 | 0.03 | 0.038 | 0.046 | 0.054 | 0.061 | 0.068 | 0.073 | 0.078 |
140 | 0.017 | 0.03 | 0.043 | 0.055 | 0.067 | 0.078 | 0.088 | 0.098 | 0.106 | 0.114 |
92 | 0.008 | 0.015 | 0.021 | 0.027 | 0.032 | 0.038 | 0.043 | 0.047 | 0.051 | 0.055 |
60 | 0.011 | 0.018 | 0.026 | 0.033 | 0.041 | 0.047 | 0.053 | 0.059 | 0.064 | 0.069 |
56 | 0.009 | 0.015 | 0.022 | 0.028 | 0.034 | 0.039 | 0.044 | 0.049 | 0.053 | 0.057 |
68 | 0.011 | 0.02 | 0.028 | 0.036 | 0.044 | 0.051 | 0.0575 | 0.064 | 0.069 | 0.074 |
60 | 0.009 | 0.016 | 0.022 | 0.029 | 0.035 | 0.041 | 0.046 | 0.051 | 0.055 | 0.059 |
248 | 0.03 | 0.052 | 0.074 | 0.096 | 0.0116 | 0.135 | 0.152 | 0.169 | 0.1825 | 0.196 |
228 | 0.025 | 0.044 | 0.063 | 0.081 | 0.099 | 0.115 | 0.1295 | 0.144 | 0.155 | 0.166 |
184 | 0.021 | 0.037 | 0.052 | 0.067 | 0.081 | 0.095 | 0.1065 | 0.118 | 0.1275 | 0.137 |
104 | 0.012 | 0.021 | 0.03 | 0.038 | 0.046 | 0.054 | 0.061 | 0.068 | 0.073 | 0.078 |
164 | 0.021 | 0.037 | 0.052 | 0.067 | 0.081 | 0.095 | 0.1065 | 0.118 | 0.1275 | 0.137 |
156 | 0.018 | 0.031 | 0.045 | 0.057 | 0.07 | 0.081 | 0.091 | 0.101 | 0.1095 | 0.118 |
Finish | ||||||||||
Vc (m/min) |
fz(mm/tooth) | |||||||||
Diameter | ||||||||||
2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | |
332 | 0.028 | 0.05 | 0.07 | 0.091 | 0.11 | 0.128 | 0.144 | 0.16 | 0.173 | 0.186 |
272 | 0.026 | 0.046 | 0.066 | 0.085 | 0.103 | 0.12 | 0.135 | 0.15 | 0.162 | 0.173 |
304 | 0.028 | 0.05 | 0.07 | 0.091 | 0.11 | 0.128 | 0.144 | 0.16 | 0.173 | 0.186 |
212 | 0.023 | 0.041 | 0.059 | 0.076 | 0.092 | 0.107 | 0.121 | 0.134 | 0.145 | 0.155 |
196 | 0.027 | 0.047 | 0.067 | 0.086 | 0.104 | 0.122 | 0.137 | 0.152 | 0.165 | 0.177 |
168 | 0.024 | 0.043 | 0.061 | 0.079 | 0.095 | 0.111 | 0.125 | 0.139 | 0.150 | 0.161 |
136 | 0.019 | 0.033 | 0.047 | 0.06 | 0.073 | 0.085 | 0.096 | 0.107 | 0.116 | 0.124 |
204 | 0.027 | 0.048 | 0.068 | 0.088 | 0.106 | 0.124 | 0.140 | 0.155 | 0.168 | 0.18 |
136 | 0.013 | 0.023 | 0.033 | 0.042 | 0.051 | 0.06 | 0.068 | 0.075 | 0.081 | 0.087 |
92 | 0.016 | 0.029 | 0.041 | 0.053 | 0.064 | 0.075 | 0.0845 | 0.094 | 0.101 | 0.108 |
84 | 0.014 | 0.024 | 0.034 | 0.044 | 0.053 | 0.062 | 0.0695 | 0.077 | 0.0835 | 0.09 |
100 | 0.018 | 0.031 | 0.045 | 0.057 | 0.07 | 0.081 | 0.0915 | 0.102 | 0.11 | 0.118 |
92 | 0.014 | 0.025 | 0.035 | 0.045 | 0.055 | 0.064 | 0.072 | 0.08 | 0.0865 | 0.093 |
364 | 0.047 | 0.083 | 0.117 | 0.151 | 0.183 | 0.214 | 0.2405 | 0.267 | 0.149 | 0.031 |
332 | 0.04 | 0.07 | 0.1 | 0.128 | 0.156 | 0.182 | 0.2045 | 0.227 | 0.245 | 0.263 |
272 | 0.033 | 0.058 | 0.082 | 0.106 | 0.128 | 0.149 | 0.168 | 0.187 | 0.202 | 0.217 |
152 | 0.019 | 0.033 | 0.047 | 0.06 | 0.073 | 0.085 | 0.096 | 0.107 | 0.1155 | 0.124 |
240 | 0.033 | 0.058 | 0.082 | 0.106 | 0.128 | 0.149 | 0.168 | 0.187 | 0.202 | 0.217 |
228 | 0.028 | 0.05 | 0.07 | 0.091 | 0.011 | 0.128 | 0.144 | 0.16 | 0.173 | 0.186 |
- If the following carbide deep groove milling cutter cannot meet your requirements, we support OEM customized production. The diameter of 0.2mm to 25mm, the total length of 50mm to 200mm, 4F, 5F, 6F, 8F and logo can be customized, including inch size end milling cutter. Please contact us to select or customize non-standard carbide end mill according to your needs.
Cutter
diameter
|
Effective
length
|
Shank
diameter
|
Overall
length
|
Flutes
|
0.2
|
2
|
4
|
50
|
2
|
0.2
|
4
|
4
|
50
|
2
|
0.3
|
2
|
4
|
50
|
2
|
0.3
|
4
|
4
|
50
|
2
|
0.4
|
2
|
4
|
50
|
2
|
0.4
|
4
|
4
|
50
|
2
|
0.4
|
6
|
4
|
50
|
2
|
0.5
|
2
|
4
|
50
|
2
|
0.5
|
4
|
4
|
50
|
2
|
0.5
|
6
|
4
|
50
|
2
|
0.5
|
8
|
4
|
50
|
2
|
0.6
|
2
|
4
|
50
|
2
|
0.6
|
4
|
4
|
50
|
2
|
0.6
|
6
|
4
|
50
|
2
|
0.6
|
8
|
4
|
50
|
2
|
0.7
|
2
|
4
|
50
|
2
|
0.7
|
4
|
4
|
50
|
2
|
0.7
|
6
|
4
|
50
|
2
|
0.7
|
8
|
4
|
50
|
2
|
0.8
|
4
|
4
|
50
|
2
|
0.8
|
6
|
4
|
50
|
2
|
0.8
|
8
|
4
|
50
|
2
|
0.8
|
10
|
4
|
50
|
2
|
0.9
|
4
|
4
|
50
|
2
|
0.9
|
6
|
4
|
50
|
2
|
0.9
|
8
|
4
|
50
|
2
|
0.9
|
10
|
4
|
50
|
2
|
1.0
|
6
|
4
|
50
|
2/4
|
1.0
|
8
|
4
|
50
|
2/4
|
1.0
|
10
|
4
|
50
|
2/4
|
1.0
|
12
|
4
|
50
|
2/4
|
1.0
|
16
|
4
|
50
|
2/4
|
1.0
|
20
|
4
|
50
|
2/4
|
1.0
|
25
|
4
|
50
|
2/4
|
1.5
|
6
|
4
|
50
|
2/4
|
1.5
|
8
|
4
|
50
|
2/4
|
1.5
|
10
|
4
|
50
|
2/4
|
1.5
|
12
|
4
|
50
|
2/4
|
1.5
|
14
|
4
|
50
|
2/4
|
1.5
|
16
|
4
|
50
|
2/4
|
1.5
|
20
|
4
|
50
|
2/4
|
1.5
|
25
|
4
|
50
|
2/4
|
2.0
|
8
|
4
|
50
|
2/4
|
2.0
|
10
|
4
|
50
|
2/4
|
2.0
|
12
|
4
|
50
|
2/4
|
2.0
|
14
|
4
|
50
|
2/4
|
2.0
|
16
|
4
|
50
|
2/4
|
2.0
|
20
|
4
|
50
|
2/4
|
2.0
|
25
|
4
|
50
|
2/4
|
2.5
|
10
|
4
|
50
|
2/4
|
2.5
|
12
|
4
|
50
|
2/4
|
2.5
|
16
|
4
|
50
|
2/4
|
2.5
|
20
|
4
|
50
|
2/4
|
2.5
|
25
|
4
|
50
|
2/4
|
3.0
|
10
|
4
|
50
|
2/4
|
3.0
|
12
|
4
|
50
|
2/4
|
3.0
|
16
|
4
|
50
|
2/4
|
3.0
|
20
|
4
|
50
|
2/4
|
3.0
|
25
|
4
|
50
|
2/4
|
Instructions OF Deep Groove Endmill
1. Before using the carbide deep groove milling cutter, please measure the tool deflection. If the tool deflection accuracy exceeds 0.01mm, please correct it before cutting.
2. The shorter the carbide extends out of the collet, the better. If the tool extends out longer, reduce the speed, feed speed or cutting amount.
3. In case of abnormal vibration or sound during cutting, please reduce the speed and cutting amount until the situation is improved.
4. Spray type and air jet type are preferred for steel cooling, which can improve the use effect of carbide deep groove endmill.
5. Note: Not suitable for low speed machines such as rotary table and electric hand drill.
Applications OF Deep Groove End Mill
Pre-hardened Steel, stainless steel, Die steel, steel plate, Heat-resistant steel,pipe, copper and aluminum, cast iron, Nonferrous Metal, Wood, Plastic,FRP and sO on. General-purpose operation slotting, rilling, profilin
Q1: The surface of the workpiece is glossy, but the concavity and convexity are large
resolvent:
(1) Reduce the feed.
(2) The low number of cutting edges changes the high number of cutting edges to improve the surface fineness.
Q2: The chip is short and thin, but there are sticky chips
resolvent:
(1) Increase cutting speed.
(2) Change to wet type (using cutting fluid), and use it with vortex tube gun to reduce the tool temperature and avoid overheating.
(3) Perform minor rounding and passivation treatment.
(4) Change from up milling to down milling.
(5) Increase the feed rate or the cutting allowance.
Q3: There are transverse cuts
resolvent:
(1) Perform minor rounding and passivation treatment.
(2) Use water-insoluble cutting fluid.
(3) Change from forward milling to reverse milling.
Q4:The finishing size is too small
resolvent:
(1) Change from up milling to down milling.
(2) Reduce the cutting allowance.
(3) Replace the chuck or spring collet.
(4) Reduce the cutting depth of the end mill.
(5) Increase cutting speed.
